| CK 18oz 系列: (強拉力) |
|
|||
| Model No. CK18oz | High Tenacity Polyester PVC Laminated Fabrics | |
| General Applications: | Construction, Marine (Field) covers, Storage covers and many other applications | |
| Colors: | Grey, White, Yellow, Red, Rose, Pink, Orange, Sky Blue, Royal Blue, Lake Blue, Apple Green, Military Green, Jade Green, Brown, Black, Coffee, Violet | |
| Available Grades: | Fire-Retardant, Ultra-Violet, Anti-Mildew, Anti-Cold | |
| Type of Products: | Roll Type, Ready Made Size Type | |
| Raw Material Origin: | From Japan | |
| Flammability Test Method: | EN 71-2:2006+A1:2007 - Flammability | |
Download Printable pdf version 下載列印版本資料
| Physical Properties: | Color Samples |
| Fabric Detail 網布規格 |
1000D x 1000D x 20 x22 | |||
| Item 項目名稱 |
Test Method 執行標準 |
Unit 單位 |
Value 數據 |
|
| Thickness 厚度 |
DIN53353 | mm | 0.55 |
|
| Total Weight 總重量 |
DIN53352 | g/m2 | 783.9 |
|
| Tensile Strength 拉伸強度 |
DIN53354 | N/5cm | 經 Warp |
2621.6 |
| 緯 Weft | 2461.5 | |||
| Elongation at Break 斷裂伸長率 |
DIN53354 | % | 經 Warp | 15.4 |
| 緯 Weft | 21.6 | |||
| Tear Strength 撕裂強度 |
DIN53363 | N | 經 Warp | 388 |
| 緯 Weft | 363 | |||
| Adhesion of Coating Strength 剝離負荷 |
DIN53357 | N/5cm | 經 Warp | 126 |
| 緯 Weft | 115 | |||
| Remarks 備註 |
||||
